Maxima Wide Body- DS


Model Maxima DS – Wider Body
Type 4-Stroke, Compression Ignition(C I), Forced air cooled and Oil cooled
Fuel required Diesel
Displacement (cc) 470.5 cc
Max Power 6.94 Kw @ 3400 rmp
Max Torque 24 Nm @ 2000 rmp
Mileage (Company) 35-37 Km Per Ltr
Starting Method Eletric Start & Pulling Rope
Transmission 4 forward + 1 reverse gear
Clutch Dry Clutch
OverAll Length 3230 mm
OverAll Width 1493 mm
OverAll Height 1818 mm
Wheel Base (mm) 2125 mm
Ground Clearance (mm)193 mm
Kerb Weight (KG) 505 kg
Weight Carrying Capacity 380 Kgs
Chasis Type Monocoque chassis with central beam and cross member welded
Brake TypeHydraulic expanding friction shoe – Leading Trailing Type
Fuel Tank (Reserve / Usable) 8 L
Head Lamp 12V35/35W
Recommended Oil 15W40
